portable eight bay open plan modular building

Ref: 287

Eight Bay Open Plan Building 64'/20m x 20'/6m. Ideal for use as Canteen, Office, Classroom, Changing Rooms etc...

£48,895 (+ vat)

enquire now

general

General

Eight Bay Open Plan Building 64’/20m x 20’/6m.

Ideal for use as Canteen, Office, Classroom, Changing Rooms etc…

specification

Specification

An eight Bay building includes as standard:-

  • Sixteen 800mm x 1100mm double glazed tilt & swing PVCu windows with insulated aluminium roller shutters.
  • Two outward opening aluminium insulated door
  • ISO Roof panels
  • Composite steel wall panels
  • Insulation – Non combustible mineral wool ·Walls 60 mm, Ceiling 60 mm, Floor 100 mm
  • Water resistant cement resin floor (no timber)
  • Single piece pvc flooring (in each module)
  • Flush ceiling mounted consumer unit (in each module)
  • Sixteen ceiling mounted fluorescent lights (two in each module)
  • Flush mounted power sockets.
  • Assembled to your floor plan (door and window positions are interchangeable)
  • Full one year manufacturers warranty

Extra doors, windows, toilets, kitchenettes, and internal partitions can be added during assembly –

Please contact us on 01298 79753 or email your ideas through to [email protected], so we can provide our best quotation.

dimension

Dimensions

Eight Bay Open Plan Building 64’/20m x 20’/6m.

delivery

Delivery

We can arrange delivery to your site with crane vehicle to place the modules on your prepared base. We can also provide a fitter on site to connect and weatherproof the building, leaving it ready for you to connect the services.

Please contact us on 01298 79753 to discuss your requirements, or email [email protected]
